Many customers prefer not to insulate the accumulator to gain some heat transfer from the air surrounding it. Insulate the accumulator to prevent condensation from forming on the outside. This is especially important on systems using POE oil.
#Accumulator on a splitt system install#
INSTALLATION Install the accumulator after the suction line filter or the orifice in these accumulators may clog if the oil into the accumulator carries wax or other debris. These ratings are those of the accumulator based on oil return through the accumulator, and will be modified by the length of the suction line and compressor displacement.ģ.Ěn accumulator should have the capability of returning liquid at the proper rate and under a range of load conditions. The recommended maximum tonnages are based on a pressure drop equivalent to 0.5?F. The accumulator should perform without adding excessive pressure drop to the system. If possible, this value should be checked based on actual tests.Ģ. Normally this should not be less than 50% of the system charge. The accumulator should have an adequate liquid-holding capacity that can vary with the system. Selection of a suction line accumulator should be made on the basis of the following three capabilities:ġ. Any heat bank that is added should be installed at the bottom of vertical accumulators and the outlet end of horizontal accumulators. Do not add too much heat or there is a risk of overheating the compressors. Heat bands are available to help boil off liquid and aid oil flow. At temperatures below this point, the oil will become thick and will not draw up the dip tube to be metered back to the compressor. Horizontal accumulators (Figure 3) should not be used when the temperature of the liquid refrigerant is less than 15?F (9?C) in the accumulator. Do not use discharge gas through the heat exchange coil or there is a risk of overheating the compressors. This can increase system efficiency while helping oil flow in the suction line.
The heat exchanger can be used on low-temperature systems to subcool the liquid line while helping to boil off liquid refrigerant in the accumulator by passing the liquid line through the heat exchanger coil. Also, check out our video on the Total Superheat Method.
#Accumulator on a splitt system full#
Check out our full article on the Total Superheat Charging Method. If the system has no superheat, the refrigerant will be saturated (Saturated means that both liquid and vapor refrigerant exist in the same location) so the vapor compressor will get damaged by the saturated refrigerant entering it. Remember that if a system has superheat, the refrigerant entering the compressor will be in vapor form. Liquid refrigerant entering a vapor compressor will damage it. In that scenario, you must set a fixed orifice system at an inefficiently high superheat just in order to keep the compressor safe from having liquid refrigerant enter the vapor compressor. If you were to take an indoor WB and outdoor DB measurement in a dry climate, and line them up on a target superheat chart, you will likely see that the target superheat is not on the chart, meaning that the target superheat number for the system is too low to print (such as 5☏ or lower). The target superheat is a moving number so it will depend on the Indoor Wet Bulb Temp and the Outdoor Dry Bulb Temp.
When charging a system with a fixed orifice, the target superheat needs to be determined.
